trabajo-11

MO120-60JD

Frecuencia
60 Hz - 1.800 rpm

Potencia
99 kWe / 124 kVA

Motor
John Deere (6068TFM50)

Descargar PDF completo

ALTERNATOR PART
Alternator	Mecc Alte	Model	ECP34 1M4C
	Stamford	Model	UCM274E
Frequency	60 Hz - 1.800 rpm
Voltage	220V	440V	480V
Phases	Triphasic
Power factor	0.8
Protection	IP23 (opcional IP44)
Class - Temp. Rise Stamford	B (70°C)	F (90°C)	H (110°C)
Class - Temp. Rise Mecc Alte	B (80°C)	F (105°C)	H (125°C)
Module droop kit integrated
Anti Condensation heater
Marine impregnation

FUEL CONSUMPTION (PRIME)
	kWm	gal/h	l/h
25%	28	2.6	9.9
50%	55	4.5	17.0
75%	84	6.1	23
100%	114	7.7	29
110%	126	8.4	31.7

ENGINE OPTIONS
EXHAUST	DRY
	WET
ELECTRIC SYSTEM	12V
	24V
COOLING SYSTEM	Heat Exchanger
	Keel Cooled
	Fan-Radiator
Warranty extension
Double Wall Fuel Lines + Leak Detection
Number of displays
Double bearing

ENGINE PART
Engine:	John Deere	Model	6068TFM50
PRIME Power Rating	115 kWm	99 kWe	124 kVA
Number of cylinders	6 cylinders in line
Displacement	6.8 liters
Aspiration:	Turbocharged
Governor	Mechanical
Combustion System	Direct Injection
Construction: SAE 3 -11.5" - coupled
Emissions	IMO	Exempt
	EPA	-

Las dimensiones están sujetas a cambios.
